566Dimensions in millimeters (inch) unless otherwise stated12 Series Fast-Lead ScrewsReceptacles %u00b7 MediumMaterial and FinishSteel, zinc immersion coating or stainless steelSide mount receptacle: 1064 steel, zinc immersion coatingPress-in receptacle: low carbon steel, case hardened and zinc plate, chromate plus sealerInstallation NotesSee page 627 for self-clinching installation guidelineswww.southco.com/12Part NumberSee tableSide Mount Receptacle Flat Type ReceptacleSelf-Clinching ReceptacleFree RunningSaddle Type Receptacle19.1(.750)32.3(1.27)Frame8.4(.33)8.4(.33)17.0(.67)%u00d8 3.3(.130) 17.0(.67)8.3 (.325)%u00d8 6.4Door (.25)Rivet Weld%u00d8 H0.6(.025)27(1.06)12.7(.50)%u00d8 H %u00d8 12.7 (.50)9.5 (.38)Min.19.1(.750) 9.5 (.375)9.5 (.375)19.1(.750)%u00d8 10.3(.405)4.7(.19)1.6(.06)%u00d8 9.5(.372)%u00d8 9.5(.375 )+0.1-0.0+.003-.0001.53 (.060)Min. sheetthickness Rivet%u00d8 3.43 (.135) Weld27(1.06)12.7(.50)7 (.28)0.5 (.02)%u00d8 H%u00d8 12.7 (.50)9.5 (.38) Min.19.1(.750)19.1(.750)9.5 (.375)9.5 (.375)Type %u00d8 H Receptacle Part NumberSteel Stainless steelSide mount receptacle ~ 12-90-101-10 ~Flat receptacle rivet2.7 (.105) 12-11015-13 12-11015-143.4 (.135) 12-11020-11 12-11020-13Flat receptacle weld-on ~ ~ 12-11016-11Press-in receptacle ~ 12-44-101-11 ~Saddle receptacle rivet 3.4 (.135) 12-11043-11 12-11043-12Saddle receptacle weld-on ~ ~ 12-11044-12
