582Dimensions in millimeters (inch) unless otherwise statedPart NumberP7-C-701Part Number includes Upper and Lower Handle Assemblies, Switch Arm, Pivot Screws, Shoulder Screw and U-Bent Washers as shown%u00d82.7 (.11)10.3 %u00b1.01 (.405 %u00b1.005)2.4 %u00b10.3(.090 %u00b1.005)10.3 %u00b1.01(.410 %u00b1.005)%u00d82.7 %u00b10.1(.106 %u00b1.005)0.62 %u00b10.1(0.02 %u00b1.005)1.78 %u00b10.1(.070 %u00b1.005)31.28 %u00b10.13(1.230 %u00b1.005)22.94 %u00b10.1(.900 %u00b1.005)%u00d82.7(.11)2.4 %u00b10.3(.090 %u00b1.005)%u00d81 %u00b10.05(0.04 %u00b1.005)6.1 (.24)4.6 (.18)5 (.2)%u00d84.3 (.17)2.3 (.09)5.3 (.21)1.6 (.06)%u00d87.8 (.31) %u00d84.7 (.18)%u00d84.3 (.17)6.1 (.24)4.6 (.18)NUMBER 1PHILLIPS RECESS%u00d8 6.1 (.24) %u00d8 4.9 (.19)4 (.16)6 (.24)5 (.2)2.3 (.09)M 2.5 WITH TORQUERESISTANT PATCH1.6 (.06)%u00d8 %u00d84.7 (.18) 7.8 (.31)2.9 (.11)%u00d84.3 (.17).5 (.02)2.3 (.09)3.8 (.15)33.8 (1.33)8 (1.3)P7 AdvancedMC%u00ae Inject / Eject MechanismModule handle & light pipe bracket panel preparationUpper Handle AssemblyUpper handle locationLower handle locationLower Handle Assembly Switch ArmPivot Screw (2 supplied) Shoulder Screw (supplied) U-Bent Washer (2 supplied)www.southco.com/P7FaceplateBlue LEDlight pipeHandle assemblyLight pipebracketassemblyPrinted circuit board assembly2 x M2.5 x 6(R2.0)(not supplied)M2.5 x 5 flush style onlyPanel PreparationAdvancedMC is a registered trademark of PICMG%u00ae - PCI Industrial Computer Manufacturers Group, Inc.%u2022 Die-cast construction for robust performance%u2022 Handle operation controls hot swap activation%u2022 Handle retention featureprevents accidental operation%u2022 For use with Carriers supporting 4 Full-size AMC ModulesMaterial and FinishHandle: Zinc alloy, black chromeLever: Zinc alloy, bright chromatePivot screw, Drag spring: Steel, zinc platedShoulder screw, U-bent washer: Stainless steel, passivatedPerformance DetailsFlammability rating: UL94-V0Installation NotesSee page 583* Captive Screws Sold Separately, See p495Carrier PCB Componet side 2Face PlateFace PlateFace PlateCarrier PCBSMK JPS1110Switch
