603ADimensions in millimeters (inch) unless otherwise statedPart Number ColorP9-064-28-T-31A000 BlackP9-064-28-T-31A00F BlueP9 Grab HandleFolding %u2022 Surface mount%u2022 Plastic handle with color options available%u2022 Low profile folding handle%u2022 Concealed InstallationMaterial and FinishHandle and Sleeve: Glass reinforced nylonPin: Stanless Steel, passivatedBase: Zinc, chromate platedPerformance DetailsMax. working load : 270 NInstallation NotesInstall assembly with M5 X 0.8 screws (screws not supplied)Maximun tightening torque of mounting screws : 2.2 NmPart NumberSee tableFor other color options, please contact Southco74.4 (2.93)72 (2.84)2x 18.9 (.75)R4 4(.16)2x %u00d810 (.40)2x %u00d87.5 (0.29)64 %u00b10.1(2.51 %u00b1.003) 2x %u00d87.6(.29) +0.102x 6.9(.27) +0.101.6 (.06)A A2x M5 x 0.8(.03) 6(.23) 2x 1.4(.05)64 (2.52)17(.67)27.9 (1.09)10.6 (.42)64 (2.52)2x %u00d810.4(.40)ReleasedPulledPanel ThicknessSpringSleeveBaseMin. ThreadHandlewww.southco.com/P9
