488Dimensions in millimeters (inch) unless otherwise statedACTUAL SIZEACTUAL SIZED4 DZUS%u00ae Standard Line Quarter-Turn FastenersReceptacles %u00b7 Size 5Material and FinishSteel, zinc plated or stainless steelMaterial and FinishSteel, zinc plated or stainless steel%u00d8 3.35%u00b1.070(.132%u00b1.003)7.15%u00b1.250(.281%u00b1.010)13.48%u00b1.380(.531%u00b1.015)H25.4 (1.00)30%u02da8.7(.343) %u00d8 3.3 (.132)Part NumberH Stud Selection ColumnSteel Stainless SteelD4-S5-200 D4-S5-200SS 5.08 (.200)AD4-S5-225 D4-S5-225SS 5.72 (.225)Rivet-On Weld-On 2 x Rivet %u00d8 8.7 (.343)19 (.75)H1.6 (.063)50.8 (2.00)Spring plate Spring %u00d8 8.7(.343)Part NumberH Stud Selection ColumnSteel Stainless SteelD4-X414-285 D4-X414-285SS 7.2 (.285)BD4-X414-310 D4-X414-310SS 7.9 (.310)www.southco.com/D4Part NumberSee tableNotesUtilize stud selection column indicated when choosing a stud length from the stud length table on pages 486-487Part NumberSee tableNotesUtilize stud selection column indicated when choosing a stud length from the stud length table on pages 486-487TMT = P + F + (Retainer adjustment value)F F FPPPTMT TMTTMT = P + F + Compressed gasketGasketTMT = P + F TMTTMT = P + F + (Retainer adjustment value)F F FPPPTMT TMTTMT = P + F + Compressed gasketGasketTMT = P + F TMTStudRetainerReceptaclePanelFrameRivet8285D8D9D1D4D5D7NY
