554Dimensions in millimeters (inch) unless otherwise stated52 Overmold Captive ScrewsMiniature series %u00b7 Flare-in styleRecess Styles*H-1P-1F*(Total float of screw in standoff)P-2 H-2Unfastened FastenedF* - Value represents float in unfastened positionNotes: P-1, P-2 measured from the top side of panel90%u02da Panel thickness%u00d8 D0.4%u00b10.1(.016%u00b1.005) %u00d8 Z45%u02da Smooth face punch (%u00d8 > screw head)Installation tool(see table)*Part Numbers not available with combination head styles; Phillips or TORX%u00ae onlyKnob Height and Screw Projection%u2022 Smaller footprint forlimited space applications%u2022 Heat treated steel screwfor optimum strength%u2022 Designate access points with color%u2022 Color match captive screws to your industrial designMaterial and FinishScre Hardened carbon steel, zinc plated, chromate, plus sealerSpring: 300 series stainless steel, passivated Standoff: Aluminum naturalKnob: PC/ABSInstallation tool: Hardened carbon steel, zinc plated, chromate, plus sealer Performance DetailsFlamability Rating: UL94-VOInstallation Notes1. Prepare panel as shown 2. Use light pressure to flare standoff, assuring parallel surfaces on the punch and installation toolPart NumberSee table%u00d8 EStandoff SpringScrewKnob%u00d8 J7.1(.28) %u00d8 B %u00d8 BLTORX%u00ae / SlotcombinationPhillips / SlotcombinationPhillips / Slot RecessNo. 2 PhillipsT15 TORX%u00ae (M3,4-40,6-32)T25 TORX%u00ae (M4)G ACTUAL SIZEwww.southco.com/52ThreadSizePanel ThicknessPart NumberBKnurledHeadBSmoothHead%u00d8 E F G H-1 H-2 %u00d8 J L P-1 P-2PanelPreparation ToolPartNo.Knurled Head Smooth Head%u00d8 D %u00d8 Z Min. Max. Phillips /SlottedTORX%u00ae/SlottedPhillips / SlottedTORX%u00ae/Slotted4-40 0.8(.031)2.4(.094)52-11-11-4-000 * 52-15-11-4-000 * 52-13-11-4-000 * 52-16-11-4-000 *8.1(.32)7.8(.31)6.2(.245)0.5(.018)2.5(.1)14(.55)9.6(.38)4.6(.183)1(.041)0.8 (.031)5.3 (.21) 4.75 (.187 ) 3(.120) 47-1046-32 1.5(.058)3.2(.125)52-29-21-4-000 52-27-21-4-000 52-2A-21-4-000 52-28-21-4-0008.8(.35)8.5(.33)7(.28)0.7(.028)2.5(.1)15(.59)9.6(.38)5.3(.209)1.8(.07)1.8 (.07)6.8 (.27) 5.41 (.213 )3.6(.141) 47-106M3 x0.50.8(.031)2.4(.094)52-31-11-4-000 * 52-35-11-4-000* 52-33-11-4-000 * 52-36-11-4-000*8.1(.32)7.8(.31)6.2(.245)0.6(.023)2.5(.1)14(.55)9.6(.38)4.6(.183)1(.041)0.8 (.031)5.3 (.21) 4.75 (.187 )3(.120) 47-104M4 x0.71.5(.058)3.2(.125)52-49-21-4-000 52-45-21-4-000 * 52-4A-21-4-000 52-46-21-4-000 *10.3(.41)10(.39)8.7(.34)0.7(.028)3(.12)15.2(.60)10(.40)6.7(.26)1.8(.07)1.8 (.07)6.8 (.27) 6.76 (.266 )4.2(.166) 47-108+0.1-0+.005-0+0.08-0+.003-0+0.08-0+.003-0+0.08-0+.003-0Specifying Color: To indicate color, change the last three digits of the part number Example: 52-11-11-4-000 Black, 52-11-11-4-013 Red000 Black(shown in table)008 Blue 013 Red014 Green Your colorcontact SouthcoTORX%u00ae is a registered trademark of CAMCAR Innovations
